Full Color P5 P6.67 P8 P10 Outdoor Aluminum Outdoor LED Screen Advertising Led Screen Display

Product Categories

SHENZHEN DDW TECHNOLOGY CO.,LTD

Contact Now

Ask Lasest Price
Brand Name :	DDWDISPLAY
Model Number :	DDW-FAPRO
Certification :	CE,ROSH,FCC,IOS9001
Payment Terms :	L/C, T/T, Western Union, MoneyGram, D/A, D/P

Add to Cart

Pixel Pitch	5mm	6.667mm	8mm	10mm
Packaging method	SMD 1921 Triple In - (Six Leg Lamp)
Brightness	8000cd/m2
Module resolution	96x64 Dots	72x48 Dots	60x40 Dots	48x32 Dots
Module size (WxH)	480mmx320mm
Pixel density	40000 pixels/m²	22500 pixels/m²	15625 pixels/m²	10000pixels/m²
Cabinet resolution	192x192Dots	144x144 Dots	120x120 Dots	96x96Dots
Cabinet size (WxHxD)	W960mmxH960mmxD100mm
Cabinet weight	27kg/m²
Maintenance method	Front and rear maintenance
Protection level	Front IP68 and rear IP66
Cabinet flatness	≤0.4mm
Module/box material	Aluminum/Die cast Aluminum
Module connection method	Hard connection design
Module signal connection point	Dual backup redundancy
Color temperature	Adjustable from 2000K to 15000K
Viewing angle	Horizontal>160 °, vertical>110 °
Physical contrast (black/white)	8:01	10:1	15:1	24:1
Reflective coefficient (white ratio)	12%	9%	6%	4%
Maximum power	700W/m²	650W/m²	660W/m²	590W/m²
Average power	70-180W/m²	70-180W/m²	70-180W/m²	70-180W/m²
Power parameters	AC 100~240V/low voltage power supply
Grayscale	16bit
Refresh rate	7680Hz
Frame frequency	50/60 Hz
Operating temperature/humidity range	-20℃~+60℃/10~90%RH
