P1.56 P1.95 P2.5 Full Color Ultra-thin Fixed Indoor LED Video Wall Indoor 4k HD High Brightness Screen

Product Categories

SHENZHEN DDW TECHNOLOGY CO.,LTD

Contact Now

Ask Lasest Price
Brand Name :	DDWDISPLAY
Model Number :	DDW-FU
Certification :	CE,ROSH,FCC,IOS9001
Payment Terms :	L/C, T/T, Western Union, MoneyGram, D/A, D/P

Add to Cart

Pixel Pitch	1.56mm	1.95mm	2.5mm	2.6mm	2.9mm	3.91mm
Optional Processes	SMD,GOB	SMD,GOB	SMD+mask	SMD+mask	SMD+mask	SMD+mask
Lamp Types	SMD1212	SMD1515	SMD1515	SMD1515	SMD1515	SMD2121
IC DRIVE	CFD455/CFD555
Scan	1/40S	1/32S	1/25S	1/32S	1/28S	1/16S
Module Size(mm)	250mmx250mm
Module Resolution(Pixels/pcs)	160*160	128*128	100*100	96*96	84*84	64*64
Module Weight(kg)	0.35kg	0.35kg	0.35kg	0.35kg	0.35kg	0.35kg
Cabinet Size(mm)	1000250/750250/500*250
Cabinet Weight(kg)	5.8kg/4.4kg/2.9kg
Pixel Density(Pixels/m²)	409600	262144	160000	147456	112896	65536
Material	Aluminum Profile
Real Brightness(cd/m²)	800-1000	800-1000	800-1000	800-1000	800-1000	1000-1200
Grey Grade	14bit/16bit
Contrast Ratio	≥ 5000:1
Brightness Uniformity	≥ 97%
Refresh Rate	7680Hz
Input Voltage	110-220V
Viewing Angle	160W/160H
Power Consumption(Max.W/m²)	560W
Power Consumption(Ave.W/m²)	280W
IP Rating(Front/Rear)	IP31
Operating Temperature	-20℃ ~ +45℃
Operating Humidity	10% ~90%RH
Storage Temperature	-10℃ ~ +40℃
Storage Humidity	10% ~60%RH
Lifespan (Hrs)	≥50,000
