Stage Rental LED Display P3.91 Indoor SMD2020 700 nits 500*500 Die-casting Aluminum 14Bit 60Hz/50Hz 3840 1/16s AC100-240V 50/60

Product Categories

SHENZHEN DDW TECHNOLOGY CO.,LTD

Contact Now

Ask Lasest Price
Brand Name :	DDWDISPLAY
Model Number :	DDW-A FLEX Series rental LED display
Certification :	CE,ROSH,FCC,IOS9001
Payment Terms :	L/C, T/T, Western Union, MoneyGram, D/A, D/P

Add to Cart

Specifications
Pixel pitch (mm)	P2.604(indoor)	P2.976(indoor)	P3.91(indoor)	P2.976(outdoor)	P3.91(outdoor)
Lamp model	SMD1515	SMD2020	SMD2020	SMD1415	SMD2020
Module pixel resolution(dots)	192*192	168*168	128*128	192*192	128*128
Module size(mm)	250*250	250*250	250*250	250*250	250*250
Pixel density (dots/m²)	147474	112896	65410	147474	65410
Brightness(nits)	700	700	700	4200	4200
white color temperature(°)	6000~10000	6000~10000	6000~10000	6000~10000	6000~10000
Viewing angle(°)	H:160V:140	H:160V:140	H:160V:140	H:160V:140	H:160V:140
Panel dimention	500*500	500*500	500*500	500*500	500*500
Cabinet material	Die-casing aluminum	Die-casing aluminum	Die-casing aluminum	Die-casing aluminum	Die-casing aluminum
Panel weight	7.5KG	7.5KG	7.5KG	7.5KG	7.5KG
Grey scale	14Bit	14Bit	14Bit	14Bit	14Bit
Frame frequency	60Hz/50Hz	60Hz/50Hz	60Hz/50Hz	60Hz/50Hz	60Hz/50Hz
refresh rate(Hz)	3840	3840	3840	3840	3840
Driving method	1/32s	1/28s	1/16s	1/21s	1/16s
Working Voldtage(V)	AC100-240V	AC100-240V	AC100-240V	AC100-240V	AC100-240V
Input Power(Hz)	50/60	50/60	50/60	50/60	50/60
Max Power consumption/panel(w)	480	480	480	480	480
Power consumption/panek(w)	160	160	160	160	160
Lifespan(H)	100000	100000	100000	100000	100000
IP Level	IP31	IP31	IP31	IP65	IP65
Life span	≥100,000H
